FEATURES:
1、Max. Height of stacking: 1600mm.
2、The splicing arm is pneumatically On/Down.
3、Hydraulic lifting system enhances the security.
4、The conveyor ramp is automatically lifting, supervised by E-eye, AUTO and MANUAL is available.
5、Auto post-splicing device can catch the paperboard correctly, which prevent the paper from mess. AUTO and MANUAL is available.
Main technical parameter
|
机型Model |
CLC-AS0920 |
CLC-AS1226 |
CLC-AS1628 |
单位 |
|
最高速度Top speed |
250 |
220 |
200 |
M/min |
|
最大通纸量Max. sheet size |
1200x2200 |
1400x2600 |
1600x2900 |
mm |
|
占地面积Machine size |
6500x3500x3000 |
6500x3970x3000 |
6500x4440x3000 |
mm |
|
机械重量Machine weight |
1800 |
2000 |
2200 |
kg |
|
使用功率Supply power |
3 |
3 |
3 |
kw |
